ABB PP835A Programmable controller

ABB PP835A Overview

The ABB PP835A is a 6.5-inch Touch Panel, part of ABB's Panel 800 series of operator panels. These Human Machine Interfaces (HMIs) are designed for visualizing and interacting with industrial automation and control systems, particularly within ABB's Compact Product Suite and Distributed Control Systems (DCS). The PP835A offers a touch-enabled interface for intuitive machine and process operation.

Product Detailed Description

• Function: The PP835A serves as an operator interface for industrial machinery and processes. It allows users to visualize process data, monitor equipment status, and control operations through a graphical touchscreen display. It's designed to provide a comprehensive and integrated HMI solution.

• Features:

• 6.5-inch TFT Touch Panel: Provides a clear visual display with touch input for user interaction.

• Graphics & Text Display: Capable of displaying both graphical elements and text.

• Color Display: Offers a full-color interface for rich visualization.

• Rugged Construction: Built with a strong yet lightweight die-cast, powder-coated aluminum housing, making it suitable for demanding industrial environments.

• IP65 Front Casing: The front panel has an IP65 rating, indicating protection against dust and water jets, suitable for wet and dusty conditions.

• Wide Operating Temperature Range: Designed to operate in a broad range of temperatures.

• Multiple Communication Options: Supports various connectivity options for local communication, expansion, and remote access. It typically includes RS422/RS485 interfaces.

• Easy to Use: Developed with customer needs in mind, featuring comprehensive and integrated templates and libraries. The Panel Builder tool, based on a familiar Microsoft® Windows® environment with multi-language support, facilitates quick and efficient configuration.

• State-of-the-Art Graphics: Utilizes vector-based, high-resolution graphics in TFT/LED display, along with icon-based interface navigation and control.

• Open Platform: Built on open architecture and technologies that accompany the .NET framework, these panels are capable of multi-brand controller connectivity.

Product Parameters

• Display Size: 6.5 inches

• Display Type: TFT Color Touch Panel

• Resolution: 640 x 480 pixels

• Touchscreen: Analog resistive

• Housing Material: Die-cast, powder-coated aluminum

• Front Protection Rating: IP65

• Operating Temperature: Typically -30°C to 70°C (Refer to specific datasheet for exact range)

• Humidity: Maximum 95% (non-condensing)

• Power Supply: 24V DC

• Communication Interfaces: RS422/RS485 (common), and other options may be available depending on the specific model/version.

• Accessories (Recommended): RX835 Touch Cover (to protect the touch screen)

Product Advantages

• Enhanced Process Visualization: High-resolution color display and advanced graphics provide clear and effective visualization of process data and machine status.

• Intuitive Operation: Touchscreen interface simplifies operation and reduces the learning curve for operators.

• Robust and Reliable: Built for demanding industrial environments with a strong IP65-rated housing and wide operating temperature range, ensuring long-term performance.

• Ease of Engineering: The Panel Builder tool with a familiar Windows environment and pre-built libraries enables quick, easy, and efficient application development.

• Versatile Connectivity: Open platform with multi-brand controller connectivity allows for flexible integration into various automation systems.

• Cost-Effective: By providing clear HMI capabilities, it helps improve operational efficiency and reduce downtime.

Precautions

• Installation: Follow ABB's official hardware and installation manual precisely. Ensure proper mounting in the panel, correct wiring for power (24V DC) and communication, and proper grounding.

• Environmental Conditions: Operate within the specified temperature, humidity, and vibration limits. While robust, avoid excessive exposure to direct sunlight, extreme temperatures, or harsh chemicals unless explicitly rated for such conditions.

• Touchscreen Protection: It is highly recommended to use the dedicated RX835 Touch Cover to protect the touchscreen from scratches, impacts, and contamination, especially in dusty or rough environments.

• Software Configuration: The panel requires configuration using ABB's Panel Builder software. Ensure the correct version of the software is used and that project files are backed up regularly.

• Power Supply: Use a stable and regulated 24V DC power supply that meets the panel's power requirements.

• ESD Protection: Take electrostatic discharge (ESD) precautions when handling the panel, especially during installation and maintenance.

• Firmware/Software Updates: Keep the panel's firmware and software updated to take advantage of continuous improvements and enhancements.

Product Applications

The ABB PP835A, as an industrial HMI, is widely used in various industrial automation and process control applications, including but not limited to:

• Machine Control: Providing operator interface for individual machines in manufacturing, packaging, and assembly lines.

• Process Visualization: Monitoring and controlling continuous processes in industries such as food and beverage, pharmaceuticals, chemicals, and water treatment.

• Building Automation: Managing building management systems, HVAC control, and energy monitoring.

• Compact Automation Systems: Used in smaller-scale automation projects where a dedicated HMI is required.

• OEM Applications: Integrated into various original equipment manufacturer (OEM) machinery.

• Distributed Control Systems (DCS): As an operator station within ABB's DCS environments.
